Sukup Support Towers are the ultimate solution for providing reliable support to bucket elevators and related equipment. These towers eliminate the need for guying cables, which can clutter facilities and occupy valuable space, providing a cleaner, more organized setup. Sukup Support Towers are engineered to not only support elevator legs but also accommodate additional equipment like bulk weighers, cleaners, and distributors, either inside or outside the tower.
Constructed with hot-dipped galvanized steel and heavy-duty bolted hardware, these towers offer exceptional durability and resistance to environmental wear. The knock-down design enables economical shipping and easy assembly, with modules available in 5', 10', and 20' sections to allow for tailored configurations. Computer-engineered and strength-staged for wind, seismic, and equipment loads, Sukup Support Towers are designed to meet high standards of structural integrity.
Optional features, such as access bracing for catwalks and conveyors, wraparound or switchback stairs, and hoist beams, provide flexibility and convenience for diverse operational needs. With a combination of robust construction, adaptability, and ease of use, Sukup Support Towers are an ideal choice for streamlining grain handling facilities.
Standard Features
- Designed per application
- Hot-dipped galvanized steel construction; ASTM A325 structural hardware
- Ideal for supporting a Sukup bucket elevator, catwalk with conveyor, or distributor
- Inverted V-bracing on 14’ x 14’ and larger; X-bracing on 12’ x 12’ and smaller
- Accessories such as bracing and platforms available as desired
- Site specific and computer engineered, strength-staged for wind, seismic, cleaner, catwalk and other loads; robust design based on ASCE 7-10
Product Accessories
- Access bracing to accommodate spout, catwalks, conveyors
- Catwalk support platforms
- Easy fit stair design, wrap around or switchback
- Internal and external platforms available
- Tie back brackets for attachment between bucket elevator and tower (bracing not provided)
- Tower base plates available for weld or anchor rod attachment to foundation
Product Features
- Hot Dipped Galvanized
